BACK TO OVERVIEW

SA-180 Situational Awareness

SA-360|180 is a naval guard, real-time object detection video analyzer that reads and understands risks, based on real-time video data from multiple sources and sensors.

Download DATASHEET

Night Sensor: 3 Sensors: 640x512 | 1280x1024 GE Window
12μm 30 FPSGE Window AR/DLC
210° Deg. (H) 3 x 70° FOV (H) 210° (V) 46°

SYSTEM OUTLINE

SENSORS

Low Light VIS Day: THREE (3) x 3840*2160/30fps SONY Super Starlight IMX678 8.0MP 4K 30FPS
FOV (H) 93.1° (V) 49.6° (D) 110.8°
Or
FOV (H) 57.1° (V) 30.4° (D)66.3°
SAPPHIRE Window

Night Sensor: 3 Sensors: 640x512 | 1280x1024 GE Window
12μm 30 FPSGE Window AR/DLC
210° Deg. (H) 3 x 70° FOV (H) 210° (V) 46°

LRF (Laser Range Finder): NA

Night Sensor: 3 Sensors: 640x512 | 1280x1024 GE Window
12μm 30 FPSGE Window AR/DLC
210° Deg. (H) 3 x 70° FOV (H) 210° (V) 46°

MOTION REQUESTS

PT: NA

SYSTEM COMPONENTS

Power: 9-36VDC, Mil.STD 1275

IP Rate: IP67, Hermetic, Nitrogen Purged

Interface: D38999 Hermetic Stainless Steel, Dual Ethernet (ONVIF/RTSP) lines + Power

Color: Black RAL9005, Anti Salt Powder
